The 3M™ RJ45 Jack FQ100031241 is a high-performance, unshielded keystone module designed to meet the rigorous demands of modern network infrastructures. As a pivotal component of the 3M™ Category 6/Class E system, this jack ensures reliable and efficient data transmission across various applications.

Key Features:

• Category 6 Compliance: Adheres to TIA/EIA 568, ISO/IEC 11801, and EN 50173 standards, guaranteeing optimal performance for high-speed data networks.

• Unshielded Design: Ideal for installations where electromagnetic interference is minimal, offering flexibility and ease of installation.

• Robust Construction: Crafted with durable plastic housing in a sleek white finish, ensuring longevity and a professional appearance.

• Versatile Compatibility: Supports both Cat5e and Cat6 cabling, making it suitable for a wide range of networking requirements.

• Easy Installation: Features an IDC (Insulation Displacement Connector) for quick and secure terminations, streamlining the setup process.

Technical Specifications:

• Product Number: FQ100031241

• Jack Type: RJ45 - 8/8

• Housing Material: Plastic

• Color: White

• Standards Compliance: ISO/IEC 11801 Edition 2, EN 50173-1:2011, ANSI/TIA/EIA-568-C.2-2009, ISO 60512-99-01

• Design and Test Criteria: IEEE 802.3 1GBASE-T, IEEE 802.3at

• Operating Temperature Range: -10°C to 60°C (14°F to 140°F)

Applications:

The 3M™ RJ45 Jack FQ100031241 is suitable for various networking environments, including:

• Office and commercial buildings

• Data centers

• Educational institutions

• Residential installations

Its unshielded design makes it an excellent choice for standard networking setups where cost-effectiveness and performance are paramount.
